Simplex Fiber Optic Pigtail

China  Simplex Fiber Optic Pigtail supplier
 Simplex Fiber Optic Pigtail supplier  Simplex Fiber Optic Pigtail supplier  Simplex Fiber Optic Pigtail supplier  Simplex Fiber Optic Pigtail supplier

Large Image :  Simplex Fiber Optic Pigtail

Product Details:

Place of Origin: Guangdong, China
Brand Name: TTI
Certification: ROHS, SGS
Model Number: FPG-PC

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiation
Packaging Details: 1PCS/PE Bag
Delivery Time: 3-5days
Payment Terms: T/T, Western Union, Monthly settlement
Supply Ability: 7000pcs/Day
Contact Now
Detailed Product Description



Premise Installations FC Simplex Fiber Optic Pigtail with 12 colors





Quick Detail:

  1. FC pigtails
  2. Cable jacket: PVC, LSZH, OFNP, OFNR
  3. Cable length: 1m, 2m, 3m, 5m....customized
  4. Cable color: Yellow, Orange, Aqua, White, Red, Green, 12corlors
  5. Insertion loss: ≤0.2dB for SM, ≤0.3dB for MM and SM/APC
  6. Return loss: ≥ 45 dB for PC, ≥ 50 dB for UPC, ≥ 65 dB for APC and ≥35dB for MM



Features:

  1. Serialized & Individual Test Records
  2. Guaranteed Zero Defects
  3. Meets ROHS and Bell core GR 326-core standards
  4. Custom Configurations Available at No Extra Charge
  5. Available in fiber bunch, ribbon fan-out, pigtail available



Applications:

  1. Premise Installations
  2. Active Device Termination
  3. Industrial, medical & military
  4. Video transmission , Data transmission
  5. Telecommunication and Data processing Networks
  6. FTTH , CATV, LAN, MAN, WAN, Test &Measuremen
  7. Systems Integration for Long Haul, Metro and Access Network



Specification:



Parameter Single Mode Multi Mode
Basic Fiber connector FC, SC, LC, ST, MU, MTRJ, MPO
Ferrule End-face PC UPC APC UPC
Insertion Loss ≤0.2dB ≤0.2dB ≤0.3dB ≤0.3bB
Return Loss ≥50dB ≥55dB ≥60dB ≥35dB
Ceramic Ferrule Specification 125.5um concentricity deviations:<=1um 127um concentricity deviations:<=3um
Suitable Fiber 9/125um 50/125um,62.5/125um
End-face Geometry Radius of Curvature 7~25mm 5~12mm N/A
Fiber Protrusion ≤50nm ≤100nm N/A
Fiber Under Cut ≤100nm ≤100nm N/A
Apex offset ≤50um
Mechanical Exchangeability ≤0.2dB
Salt Spray ≤0.1dB
Drop ≤0.2dB(1.5M, 5 drops)
Vibration IL ≤0.2dB(550Hz, 1.5mm)
Repeatability ≤ 0.1dB(1000 times)
Durability > 1000 times
Operating Temperature -40°C ~ +85°C





Ordering Information:

Step 1: Connector Type: FC, SC, LC, ST, MTRJ, MU, MPO

Step 2: Ferrule End-face: PC, UPC or APC

Step 3: Fiber Type: Single Mode(SM) or Multimode

Step 4: Cable Core: Simplex or Duplex

Step 5: Cable Diameter: 0.9mm, 2.0mm or 3.0mm

Step 6: Cable Length: 1, 2, 3 meter or customized

Step 7: Cable Type: PVC, LSZH, OFNR, OFNP…

Step 8: Cable color: Yellow, Orange, White, Blue, Green, Red, ...





Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)



Packing:



One piece per PE bag with stick label (we could add customer's logo in the label.)
