SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector

SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector

Product Details:

Place of Origin: Guangdong, China
Brand Name: TTI
Certification: ROHS, CE
Model Number: SC Adapter

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton Box
Delivery Time: 2-3 days
Payment Terms: T/T, L/C, PayPal
Supply Ability: 10000pcs/day
Get Best Price Contact Now

Detail Information

Brand: TTI/OEM/ODM Product: Fiber Optic Adapter
Feature: Low Insertion Loss Value Application: Local Area Network
Operating Temperature: -25~75 Degree -25~75 Degree: -40~85 Degree
High Light:

Fast Connector Fiber Optic Duplex Adapter

,

Singlemode Fiber Optic Duplex Adapter

Product Description

Factory Price Fiber Optic SC DX Apc Upc Sm Mm Om Duplex Adapter For Fast Connector





Quick Details

  1. Type: SC/APC
  2. Mode: Singlemode
  3. Fiber core: Simplex, Duplex
  4. Structure: with flange, without flange
  5. Sleeve: Ceramic sleeve
  6. Housing: Plastic housing



Description:



Fiber Optic Adapter is the mechanical device designed to align fiber optic connectors. It contains the interconnect sleeve, that holds the two ferrules together.



Product Display:



SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector 0

SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector 1

SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector 2

SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector 3

SC DX Apc Upc Sm Mm Om Fiber Optic Duplex Adapter For Fast Connector 4



Features:

  1. SC used pluggable tight locking structure
  2. Standardization and Uniformization of Metal Casing
  3. Zirconia or Bronze Sleeve
  4. Low Insertion Loss, high Return loss
  5. Precision mechanical dimension
  6. Good repeatability, interchangeability and environmental stability



Application:

  1. Equipment Test
  2. Local Area Network
  3. Optic instrumentation
  4. CATV system, Optic LAN
  5. Telecommunication Networks
  6. Fiber optic communication network
  7. Optical Broadband Access Network



Specification:



Type SC/FC/ST/LC/MU/MTRJ/MPO
Insertion Loss(dB) SM≤0.2dB, MM≤0.3dB
Repeatability(dB) ≤0.1dB
Mechanism Durability(500 cycles, dB) ≤0.2dB
Temperature Range -40°C-+85°C
Material of sleeve Zirconia or Bronze





Reliability testing:



Item Test Name Additional Insertion Loss Additional Return Loss
1 Mechanical durability <0.2dB <5dB
2 Repeatability <0.2dB <5dB
3 Lock strength <0.2dB <5dB
4 Low strength <0.2dB <5dB
5 High temperature <0.2dB <5dB
6 Steaming <0.2dB <5dB
7 Temperature cycle <0.2dB <5dB
8 Vibration <0.2dB <5dB
9 Drop <0.2dB <5dB





Ordering Information:



SC/UPC-SC/UPC-SM-SX



Step 1: Connector type: FC, SC, LC, ST, MTRJ, MU, MPO

Step 2: Ferrule End-face: PC, UPC, APC

Step 3: Type: Single-mode, Multimode (MM, OM3, OM4)

Step 4: Mode: Simplex, Duplex

Step 5: Sleeve: Ceramic, Bronze

Step 6: Housing material: Plastic, Metal





ODM Duplex Fiber Optic Patch Cord Multimode For FTTH Communication Rooms 8

ODM Duplex Fiber Optic Patch Cord Multimode For FTTH Communication Rooms 9


ODM Duplex Fiber Optic Patch Cord Multimode For FTTH Communication Rooms 10



Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)



FAQ:



1. Why choose TTI FIBER ?
(1) Professional manufacturer: low MOQ, free samples are available.
(2) Quality assurance: stable high quality.
(3) Customers solutions: quick.
(4) Win-Win Price: save much costs, bring more benefits for customers.


2. Do you accept OEM,ODM?
Yes, we accept them .


3. Can you print our LOGO?
Sure, Your LOGO can be printed on the boxes, or products.


4. What's the method of shipment?
We accept all shipment, such as Delievery, ocean transport, land transport, airport transport.
