Optical Fiber Adapter Optic Adapter LC/APC Single Mode Duplex Coupler Coupling Adapter Connector
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | TTI |
| Certification: | ROHS, SGS |
| Model Number: | A02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25pcs/Case |
| Delivery Time: | 2-3 days |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/day |
|
Detail Information |
|||
| Brand: | TTI | Product: | Fiber Optic Adapter |
|---|---|---|---|
| Feature: | Low Insertion Loss Value | Application: | Local Area Network |
| Operating Temperature: | -25~75 Degree | -25~75 Degree: | -40~85 Degree |
| Product Name: | Fiber Optic Adapter, Hot Selling Simplex Orange Optical Fiber Adapter For Patch Cord, FC Adaptor Metal Plastic Cap Single Mode Optic Fiber Adapter, Outdoor Fiber Optic Distribution Box Patch Cord Box, SC/UPC Single Mode Duplex Fiber Optic Adapter | Color: | Green, Blue, Red, Gray, Blue /Beige /Green |
| Type: | Singlemode, Single Mode/ Multi-mode, Duplex, PC/UPC/APC, Single Mode Multi Use | Insertion Loss: | ≤0.2dB, ≤ 0.2dB(SM&MM), <0.2, IL<0.2db, <0.3db |
| Application: | FTTH FTTB FTTX Network, LC/UPC-LC/UPC, Indoor/outdoor, Network, Telecommunication/Fiber Optic CATV/Multimedia | Certification: | ISO9001, RoHS, CE, ROSH N Type Attenuator, Telecom |
| Material: | PVC, Copper, ABS PC, Zinc Alloy, Metal | Connector Type: | SC, FC, DIN, Dul LC/SC/FC/ST, LC |
| Return Loss: | >55dB, 50db, >60db, UPC≥55dB | Durability: | < 0.2db Typical Change, 1000 Time Matings, >1000time |
| High Light: | LC/APC Fiber Optic Adapter,SGS Fiber Optic Adapter,Single Mode Duplex Coupling Adapter |
||
Product Description
Optical Fiber Adapter Optic Adapter LC/APC Single Mode Duplex Coupler Coupling Adapter Connector
Quick Details
- Type: SC/UPC
- Mode: Singlemode
- Fiber core: Simplex, Duplex
- Structure: with flange, without flange
- Sleeve: Ceramic sleeve
- Housing: Plastic housing
Description:
Fiber Optic Adapter is the mechanical device designed to align fiber optic connectors. It contains the interconnect sleeve, that holds the two ferrules together.
Features:
- SC used pluggable tight locking structure
- Standardization and Uniformization of Metal Casing
- Zirconia or Bronze Sleeve
- Low Insertion Loss, high Return loss
- Precision mechanical dimension
- Good repeatability, interchangeability and environmental stability
Application:
- Equipment Test
- Local Area Network
- Optic instrumentation
- CATV system, Optic LAN
- Telecommunication Networks
- Fiber optic communication network
- Optical Broadband Access Network
Specification:
| Type | SC/FC/ST/LC/MU/MTRJ/MPO |
| Insertion Loss(dB) | SM≤0.2dB, MM≤0.3dB |
| Repeatability(dB) | ≤0.1dB |
| Mechanism Durability(500 cycles, dB) | ≤0.2dB |
| Temperature Range | -40°C-+85°C |
| Material of sleeve | Zirconia or Bronze |
Reliability testing:
| Item | Test Name | Additional Insertion Loss | Additional Return Loss |
| 1 | Mechanical durability | <0.2dB | <5dB |
| 2 | Repeatability | <0.2dB | <5dB |
| 3 | Lock strength | <0.2dB | <5dB |
| 4 | Low strength | <0.2dB | <5dB |
| 5 | High temperature | <0.2dB | <5dB |
| 6 | Steaming | <0.2dB | <5dB |
| 7 | Temperature cycle | <0.2dB | <5dB |
| 8 | Vibration | <0.2dB | <5dB |
| 9 | Drop | <0.2dB | <5dB |
Ordering Information:
SC/UPC-SC/UPC-SM-SX
Step 1: Connector type: FC, SC, LC, ST, MTRJ, MU, MPO
Step 2: Ferrule End-face: PC, UPC, APC
Step 3: Type: Single-mode, Multimode (MM, OM3, OM4)
Step 4: Mode: Simplex, Duplex
Step 5: Sleeve: Ceramic, Bronze
Step 6: Housing material: Plastic, Metal
Packing:
25pcs per PE bag with stick label (we could add customer's logo in the label.)
Shipping:
- Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
- Airport to Airport: by air
- Seaport to Seaport: by sea (our location Shenzhen is a seaport.)
Our service:
- Standard and customized OEM products from small to large quantity are welcome.
- Compliance with global environmental industry with RoHS and SGS standards.
- All products are 100% fully tested by our technical expertise.
