• 0.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core
0.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core

0.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core

Product Details:

Place of Origin: Guangdong, China
Brand Name: TTI
Certification: ROHS, CE
Model Number: FPG

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1PCS/PE Bag
Delivery Time: 3-5 days
Payment Terms: T/T, L/C, Western Union, PayPal
Supply Ability: 7000pcs/Day
Get Best Price Contact Now

Detail Information
Color: Blue, Yellow/orange/Aqua, Aqua, Yellow, Orange Length: 1M/2M/3M So On
Connector Type: SC/LC/ST/FC Insertion Loss: ≤0.20, MM≤0.75dB, SM≤0.50dB, ≤0.1dB, IL<0.2db
Connector: FC, SC, SC/APC (LC, LC, FC For Choice) Fiber Type: SM 9/125 G652D, OS1, 9/125 Tight Buffered Fiber Single Mode Simplex, G652D/G657A1/G657A2 Etc., G657A1 Etc.
High Light:

ST FC PC Pigtail

,

0.9mm FC PC Pigtail

,

Duplex Pigtail Fiber Optic

Product Description

FTTH Fiber Optic Pigtail LC SC ST FC PC UPC APC Simplex SInglemode SM 0.9mm Fiber Optic Patch Cord Pigtail





Quick Detail:

  1. Cable jacket: PVC, LSZH, OFNP, OFNR
  2. Cable color: Yellow, Orange, Aqua, White, Red, Green, 12corlors
  3. Insertion loss: ≤0.2dB for SM, ≤0.3dB for MM and SM/APC
  4. Return loss: ≥ 45 dB for PC, ≥ 50 dB for UPC, ≥ 65 dB for APC and ≥35dB for MM
  5. Cable length: 1m, 2m, 3m, 5m....customized
  6. Cable core: simplex, duplex, 6core,12core, 24core, 48core… customized





Description:



ABS Module Type splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It’s mainly used for various connection and distribution boxes or network cabinets.

The PLC splitter we offer are:1×2,1×3,1×4,1×6,1×8,1×16,1×32,1×64, 1x128 ; 2×4,2×8,2×16,2×32,2×64,2x128

Our products meet Telcordia 1209,1221 standard ,ROHS.





Features:

  1. Low Insertion loss and Low PDL
  2. Good channel-to-channel uniformity
  3. Wide Operating Wavelength: From 1260nm to 1650nm
  4. Wide Operating Temperature: From -40℃ to 85℃
  5. High Reliability and Stability
  6. Stability Telecordia GR-1221 and GR-1209



Applications:

  1. FTTH application
  2. Premise installations
  3. Data processing networks
  4. Wide Area Networks (WANs)
  5. Industrial ,mechanical and military



Specification:





Parameter Single Mode Multi Mode
Basic Fiber connector FC, SC, LC, ST, MU, MTRJ, MPO
Ferrule End-face PC UPC APC UPC
Insertion Loss ≤0.2dB ≤0.2dB ≤0.3dB ≤0.3bB
Return Loss ≥50dB ≥55dB ≥60dB ≥35dB
Ceramic Ferrule Specification 125.5um concentricity deviations:<=1um 127um concentricity deviations:<=3um
Suitable Fiber 9/125um 50/125um,62.5/125um
End-face Geometry Radius of Curvature 7~25mm 5~12mm N/A
Fiber Protrusion ≤50nm ≤100nm N/A
Fiber Under Cut ≤100nm ≤100nm N/A
Apex offset ≤50um
Mechanical Exchangeability ≤0.2dB
Salt Spray ≤0.1dB
Drop ≤0.2dB(1.5M, 5 drops)
Vibration IL ≤0.2dB(550Hz, 1.5mm)
Repeatability ≤ 0.1dB(1000 times)
Durability > 1000 times
Operating Temperature -40°C ~ +85°C



Ordering Information:



Step 1: Connector Type: FC, SC, LC, ST, MTRJ, MU, MPO

Step 2: Ferrule End-face: PC, UPC or APC

Step 3: Fiber Type: Single Mode(SM) or Multimode

Step 4: Cable Core: Simplex or Duplex

Step 5: Cable Diameter: 0.9mm, 2.0mm or 3.0mm

Step 6: Cable Length: 1, 2, 3 meter or customized

Step 7: Cable Type: PVC, LSZH, OFNR, OFNP…

Step 8: Cable color: Yellow, Orange, White, Blue, Green, Red, ...



Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)



Our service:

  1. Standard and customized OEM products from small to large quantity are welcome.
  2. Compliance with global environmental industry with RoHS and SGS standards.
  3. All products are 100% fully tested by our technical expertise.
  4. Our patch cord warranty period is one year.



Packing:

One piece per PE bag with stick label (we could add customer's logo in the label.)





0.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core 00.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core 10.9mm ST FC PC Pigtail Fiber Optic Simplex Duplex 6core 12core 2



FAQ

Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our company mainly produces optical fiber products.

Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
