Outdoor Indoor FTTH GJYXCH Drop Cable G657A G652D 1 2 Core Fiber Home Fibra 1km 2km Fiber Optic Cable
Product Details:
| Place of Origin: | China |
| Brand Name: | TTI |
| Certification: | ROHS,CE |
| Model Number: | GJYXCH Fiber Optic Drop Cable |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Package(Surport OEM/ODM) |
| Delivery Time: | 5-8 Work Days |
| Payment Terms: | D/A, D/P, T/T... |
| Supply Ability: | 100000 meters |
|
Detail Information |
|||
| Product Name: | GJYXCH Fiber Optical Drop Cable | Application: | Outdoor Fiber Optic Cable |
|---|---|---|---|
| Color: | Black | Material: | LSZH PE |
| Fiber Type: | G652D G657A1 G657A2 | Certification: | ROHS,CE,ISO14001,ISO9001 |
| Use: | FTTX | Length: | Customizted |
| Quality Control: | 100% Test Before Shipping | Package: | Wooden Ram |
| Highlight: | FTTH fiber optic drop cable,G657A fiber optic cable,indoor outdoor fiber cable |
||
Product Description
Outdoor Indoor FTTH GJYXCH Drop Cable G657A G652D 1 2 Core Fiber Home Fibra 1km 2km Fiber Optic Cable
GJYXCH Drop Cable LZSH Single Mode 1 2 4 Core G652D G657A1 G657A2 Outdoor Aerial FTTH Fiber Drop Optic Cable
GJYXCH Drop Cable Construction / Cross Sectional Diagram
Technical Specification
| Items | Specification |
|---|---|
| Fiber count | 1/2/4F |
| Fiber | Out diameter(±5μm): 250 |
| Outer sheath | Self supporting element: 1.0mm Steel wire |
| Tensile element | 2*0.4mm Steel wires |
| Sheath material | LSZH |
| Color | Black |
| Out diameter | 5.1(±0.2)*2.0(±0.1) mm |
| Cable weight(kg/km) | 22 |
Optical Fiber Specifications
| Fiber type | G652D (1310/1550nm) | G657A1 (1310/1550nm) | G657A2 (1310/1550nm) |
|---|---|---|---|
| Attenuation | Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
| Zero Dispersion Slope | ≤0.091 ps/km*nm2 | ≤0.092 ps/km*nm2 | ≤0.092 ps/km*nm2 |
| Dispersion(1285~1340nm) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) |
| Mode field Diameter(@1300nm) | 9.3±0.4 µm | 8.8±0.4 µm | 8.8±0.4 µm |
| Cutoff wavelength cable(nm) | ≤1260 nm | ≤1260 nm | ≤1260 nm |
| Min bend radius(mm) | 16 mm | 10 mm | 7.5 mm |
| Cladding diameter(µm) | 125±1.0 | 125±1.0 | 125±1.0 |
Mechanical and Environmental Performance
| Mechanical properties | Installation | Operation |
|---|---|---|
| Tensile strength | 300N | 600N |
| Min bend radius | 15mm | 30mm |
| Crush resistance | 2000N/100mm | |
The mechanical properties of other optical fibers and cables shall meet international standards of IEC 60794.
Temperature Specifications
| Transportation temperature | -20℃~+60℃ |
| Storage temperature | -20℃~+60℃ |
| Installation temperature | -20℃~+60℃ |
| Operation temperature | -20℃~+60℃ |
