OM3 / OM4 UPC LSZH Fiber Optic Patch Cord with Red Black Boot
Product Details:
| Place of Origin: | China Mainland |
| Brand Name: | TTI |
| Certification: | ROHS, SGS |
| Model Number: | FPC-LC |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1pcs/PE bag |
| Delivery Time: | in 2-4 days |
| Payment Terms: | T/T, , ESCROW, PayPal, Monthly settlement |
| Supply Ability: | 7000pcs/Day |
|
Detail Information |
|||
| High Light: | multimode fiber patch cord,fiber optical cable |
||
|---|---|---|---|
Product Description
OM3 / OM4 PC UPC LSZH Fiber Optic Patch Cord with Red Black Boot
Quick Details:
- Boot color: Red, Black
- Mode: OM3, OM4
- Cable core: Duplex
- Ferrule End-face: PC, UPC
- Cable diameter: 0.9mm, 2.0mm, 3.0mm
- Cable color: Orange, Aqua, Volient
Features:
- Guaranteed Zero Defects
- Insertion & Return Loss Tested
- Serialized & Individual Test Records
- Meets Telcordia Endface GeometryRequirements
- Custom Configurations Available at No Extra Charge
Applications:
- Optical access network
- Telecommunication networks
- Fiber optic communication networks
- CATV, LAN, MAN, WAN, Test &Measurement
Specification:
| Item | Single Mode | Multi Mode |
| Insertion Loss | <= 0.2dB | <= 0.3bB |
| Return Loss | PC≥50dB, UPC≥55dB, APC≥60dB | |
| Insert-pull Test | 1000 times | |
| Repeatability | <=0.1 | |
| Tensile strength | ≥10KG | |
| Operating Temperature | -40°C ~ +85°C | |
| Ceramic Ferrule Specification | 125.5um concentricity deviations:<=1um | 127um concentricity deviations:<=3um |
| Suitable Fiber | 9/125um | 50/125um,62.5/125um |
Packing:
One piece per PE bag with stick label (we could add customer's logo in the label.)
Shipping:
- Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
- Airport to Airport: by air
- Seaport to Seaport: by sea (our location Shenzhen is a seaport.)
