G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube

Product Details:

Place of Origin: Guangdong, China
Brand Name: TTI
Certification: ROHS, SGS
Model Number: FOC-FRP

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden drum with test report
Delivery Time: 3-5 days
Payment Terms: T/T, , PayPal, D/A, L/C,
Supply Ability: 100000M/Day
Get Best Price Contact Now

Detail Information
Length: 2-3km/drum Application: FTTH, OUTDOOR, Aerial, Armored Outdoor Optic Fiber Cable, Audio Signal Transmission
Number Of Conductors: ≥ 10, 2, 6 Fiber Type: G652D, G657A2, Single Mode Or Multi Mode, G657, Single Mode Fiber
Type: Coaxial, FTTH 24 Core Optical Fiber Cable, Professional Manufactures Fiber Optic Sma Connector, Bare Optical Fiber, Single-Mode Or Multi-Mode Color: Black, Usually Black Color, Blue Or Others, Aqua, Yellow
Fiber Count: 2 Core, 2/4/6/8/12 Core, 1-144 Core, 1 Cores, 1/2/4 Core Jacket Material: LSZH, PVC, PE, TPU, PVC/LSZH
High Light:

G652D Outdoor Fiber Patch Cable

,

G657A2 Outdoor Fiber Patch Cable

,

G657A2 outdoor optical cable

Product Description

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube



Quick Detail:

  1. Outdoor Fiber Optic Cable
  2. FRP Central Strngth member
  3. Mode: Single mode, Multimode
  4. Fiber core: 2~144 cores
  5. Application: Duct and Aerial, Direct Buried
  6. Jacket: PE outer jacket



Features:

  1. Good mechanical and temperature performance
  2. High strength loose tube that is hydrolysis resistant
  3. Tube filling compound- gel
  4. PBT-made loose tubes
  5. Cable filling compound



Application:

  1. Usable in Duct or Aerial
  2. Junction communication system
  3. Local area network systems
  4. Long-haul communication system



Technical Parameters:

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 0

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 1

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 2





G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 3

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 4

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 5





Cable Type Fiber Count Tubes Fillers Cable Diameter
(mm)		 Cable Weight
(kg/km)		 Tensile Strength (N) Crush Resistance
(N/100mm)		 Bending Radius
(mm)
Long/Short Term Long/Short Term

Static/

Dynamic
GYTS-2~6 2~6 1 4 10.2 116 600/1500 300/1000 10D/20D
GYTS-8~12 8~12 2 3 10.2 116 600/1500 300/1000 10D/20D
GYTS-14~18 14~18 3 2 10.2 116 600/1500 300/1000 10D/20D
GYTS-20~24 20~24 4 1 10.2 116 600/1500 300/1000 10D/20D
GYTS-26~30 26~30 5 0 10.2 116 600/1500 300/1000 10D/20D
GYTS-32~36 32~36 6 0 10.6 129 1000/3000 300/1000 10D/20D
GYTS-38~48 38~48 4 1 11.2 141 1000/3000 300/1000 10D/20D
GYTS-50~60 50~60 5 0 11.2 141 1000/3000 300/1000 10D/20D
GYTS-62~72 62~72 6 0 12 159 1000/3000 300/1000 10D/20D
GYTS-74~84 74~84 7 1 13.6 209 1000/3000 300/1000 10D/20D
GYTS-86~96 86~96 8 0 13.6 209 1000/3000 300/1000 10D/20D
GYTS-98~108 98~108 9 1 15.4 232 1000/3000 300/1000 10D/20D
GYTS-110~120 110~120 10 0 15.4 232 1000/3000 300/1000 10D/20D
GYTS-122~132 122~132 11 1 17.2 280 1000/3000 300/1000 10D/20D
GYTS-134~144 134~144 12 0 17.2 280 1000/3000 300/1000 10D/20D



Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 6

G657A2 G652D Outdoor Fiber Patch Cable FRP Strength Loose Tube 7
