Home ProductsFiber Optic Patch Cord

CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket

CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket

    • CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket
    • CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket
    • CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket
  • CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket

    Product Details:

    Place of Origin: China Mainland
    Brand Name: TTI
    Certification: ROHS, SGS
    Model Number: OM3-LCU

    Payment & Shipping Terms:

    Minimum Order Quantity: 20
    Price: Negotiation
    Packaging Details: 1pcs/PE bag
    Delivery Time: in 2-4 days
    Payment Terms: T/T, Western Union, ESCROW, PayPal, Monthly settlement
    Supply Ability: 7000pcs/Day
    Contact Now
    Detailed Product Description



    CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket



    Quick Details:

    1. Name: Uniboot LC patch cord
    2. Boot color: Beige
    3. Mode: OM3, OM4, OS1, OS2, OM1, OM2
    4. Ferrule End-face: PC, UPC, APC
    5. Cable core: Duplex
    6. Cable length: 1m, 2m, 3m….customized



    Features:

    1. Good interchange
    2. Good repeatability
    3. Low insertion loss, high return loss
    4. Clean and Scratch-Free End Face
    5. High Quality 100% Factory Tested
    6. 3D fiber interferometer is available



    Applications:

    1. Telecommunication networks
    2. Fiber optic communication networks
    3. CATV, LAN, MAN, WAN, Test &Measurement
    4. Optical access network



    Specification:

    Parameter Unit FC, SC, LC ST, MU MT-RJ, MPO
    SM MM SM MM SM MM
    PC UPC APC PC PC UPC PC PC UPC PC
    Insertion loss(typical) dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2
    Return loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥30 ≥45 ≥50 ≥35
    Operating wavelength nm 1310, 1510 1310, 1510 1310, 1510
    Exchangeability dB ≤0.2 ≤0.2 ≤0.2
    Durability dB >1000 >1000 >1000
    Operating temperature °C -40~75 -40~75 -40~75
    Storage temperature °C -45~85 -45~85 -45~85
    Cable diameter mm φ3.0, φ2.0, φ0.9 φ3.0, φ2.0, φ0.9 φ3.0, φ2.0, φ0.9



    Packing:

    One piece per PE bag with stick label (we could add customer's logo in the label.)



    Shipping:

    1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
    2. Airport to Airport: by air
    3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)

    CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacketCATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket

    CATV / LAN / MAN / WAN / Test LC Uniboot Fiber Optic Patch Cord with Violet LSZH jacket
