Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db

Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db

Product Details:

Place of Origin: Guangdong, China
Brand Name: TTI
Certification: ROHS, SGS
Model Number: 001

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1PCS/PE Bag
Delivery Time: 2-3 days
Payment Terms: T/T
Supply Ability: 5000pcs/Day
Get Best Price Contact Now

Detail Information

Product: Fiber Optic Attenuator Brand: Tti
Application: Lan Feature: Good Stability
Attenuation Range: 1-10db Operating Wavelength: Sm 1310/1550nm Mm 850/1300nm
Operating Temperature: -25~75 Degree Storage Tempt.: -40~85 Degree
Wavelength: 1260 To 1650nm, 1550nm, 1310/1550nm Certification: ISO, ISO9001
Connector Type: LC SC FC ST, Lc Type: Male To Female, Male-female
Connector: SC, SC/APC OR FC/APC Material: Metal, Plastic
Attenuation Tolerance: 5dB ± 0.5dB, 10dB ±1dB, Others Fiber Type: Single Mode, Singlemode
High Light:

singlemode fixed fiber optic attenuator

,

5db fixed fiber optic attenuator

,

10db single mode attenuator

Product Description

Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db


Quick Detail:

  1. Name: Fixed Fiber optic attenuator
  2. PC, UPC, and APC polish types optional
  3. attenuation fiber inside
  4. SC,LC,FC,ST,MU Optional
  5. Mode: Singlemode, Multimode
  6. Operating Wavelength: 1310nm, 1550nm, 850nm, 1300nm



Description:



Attenuators are also used to balance out transmission lines that otherwise would have unequal signal levels.



Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 0  Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 1



Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 2  Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 3

Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 4Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 5

Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 6             Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 7



    Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 8         Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 9



Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 10                   Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 11





Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 12                        Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 13



Features:

  1. Complied with Telcordia (GR-910-CORE and GR-1221-CORE).
  2. Visual Tested with 800X magnification: Three Times (After Polishing, Before Assembly, Before Delivery)
  3. 100% Geometrical Inspection: Radius(10-25mm/PC), Offset(0-50um), Fiber Height(+/-50nm)
  4. High Optical Power Endurance: up to 1000mW (=1W)
  5. High Reliability: Specified for Over 500 mating



Application:

  1. Fiber Optic Communication Systems
  2. DWDM Equipment
  3. Fiber Optic CATV
  4. Optical LAN
  5. Optical CATV
  6. Local Area Networks
  7. Optical fiber communication networks



Specification:



Attenuation value 1,3, 5,10, 15, 20, 25 dB
Attenuation precision 5dB±0.3dB
10dB±1dB
10dB±10%
Return loss PC 45dB APC60dB
Operation wavelength 1310nm and 1550nm(SM)
Polarization loss 0.1dB
Operation temperature -40°C ~ +75°C
Storage temperature -40°C ~ +85°C
Temperature(Unencapsulation) 95%RH Apply Telecordia standard(GR-910-CORE)





Ordering Information:



FC/UPC-SM-15dB-Fixed



Step 1: Connector type: FC, SC, LC, ST, MU

Step 2: Ferrule End-face: PC, UPC, APC

Step 3: Type: Single-mode, Multimode

Step 4: Attenuation: 1-10dB(1dB step), 15, 20, 25, 30dB

Step 5: Mode: Fixed, Female&Male, In-line, Variable

Step 6: Wavelength: 1310nm, 1550nm, 850nm, 1300nm





Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)



Our service:

  1. Standard and customized OEM products from small to large quantity are welcome.
  2. Compliance with global environmental industry with RoHS and SGS standards.
  3. All products are 100% fully tested by our technical expertise.
  4. we could add customer's logo in the label.



Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 14Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 15Fibre Attenuator Lc/Upc Singlemode Fixed Fiber Optical Attenuator 5db 10db 15db 16





1. Why choose TTI FIBER?


(1)Professional manufacturer: Low MOQ, free samples are available.
(2)Quality assurance:Stable high quality.
(3)Customers solutions:Quick.
(4)Win-Win Price:Save much costs, bring more benefits for customers.

2.Do you accept OEM,ODM?
Yes, we accept them .

3.Can you print our LOGO?
Sure, Your LOGO can be printed on the boxes , or products.

4.What's the method of shipment?
We accept all shipment , such as Delievery,ocean transport, land transport , airport transport.
